Suspension kit Sport ST4 TeraFlex Lift 4,5"

• Lift Height: 4,5”
• Delivers true Street & Trail (ST) performance
• Dependable performance w/ zero worries
• Positive, responsive handling w/ reduced NVH
• Front (3.5”+) and Rear (2.5”+) Track Bar Brackets correct caster angle, steering geometry, center the axles, and reduce body roll
• Falcon Progressive Front & Rear Bump Stops protect occupants and the vehicle from hard suspension bottoming
• Full range of movement for off-road flex and articulation
• Install and drive, simple bolt-on installation – no welding required
• No alignment require

Max tyre diameter:

• Sport/Sahara Fenders: 35” (w/ 3” front & 2.5” rear bump stops)
• Sport/Sahara Fenders: 37” (w/ 3.5” front & 4” rear bump stops)
• Rubicon Fenders: 37” (w/ 2.5” front & 3” rear bump stops)
• 39": Aftermarket high fenders, rear bump extension and shims

In the box:

• Front Control Arm Sport Brackets
• Front Track Bar Bracket
• Front Brake Line Anchor Kit
• Longer 11,5” Front Sway Bar Links Kit
• Rear Track Bar Bracket
• Longer 10,75” Rear Sway Bar Links Kit
• Front & Rear Falcon Progressive Bump Stop Kit
• Front & Rear 2" Bump Stop Strike Pad Extension Kit
• Front & Rear 0,5" Bump Stop Strike Pad Shim Kit
• 4,5” Lift Coil Springs
• All necessary hardware

Notes:

• Requires aftermarket wheels w/ 4.75” backspacing or less – or Offset Wheel Adapters for stock wheels (sold separately)
• Models with plastic bumpers require removal of bumper-to-fender wind deflector/splash guards in order to fit 35” or larger tyres
• JL/JLU: Sport Bracket HD Reinforcement Kit (1938115) beefs up the Front Control Arm Sport Brackets. Recommended, but not required
• Requires longer shocks (not included in base kit) – Falcon shock absorbers recommended
