CNPY SMTH DC DMAX 2016+ 2SWWDR

CLASSIC CANOPY

Unrivalled quality, practicality and affordability.

Available as a standard height roof version in smooth, painted exterior finish.

Product Specification

The front canopy window is a lift style to allow maximum rearward vision and easy access to clean the vehicle cabin rear glass.

The rear door is a full 3D curve design, manufactured from aluminum. Each rear door is fitted with a high mount LED stop lamp, a forward facing interior light and specially selected gas assist struts with low opening force suitable for a climate range of -20-¦C to 90-¦C.

ARB's unique laser cut steel mount system is bolted directly to the existing vehicle hard points located at the front and rear of the vehicle tub to form a solid foundation for the canopy whilst additional brackets have been added to the rear of the side bedrails to support the rear door frame and door strikers.

ARB canopy shells are made from a special co-extruded ABS plastic for strength and durability. The ABS is inert and with suitable venting is safe for the transportation of animals. Being a recyclable material, we have the opportunity to reduce the amount of landfill at end of product life.

Features

• \t
• Heavy duty 8mm ABS plastic canopy shell suitable for temperatures -20-¦C to 90-¦C\t
• 5mm thick tempered safety glass with dark grey tint (28% visual light transmission) manufactured to international standard ECE43R\t
• E Mark approved LED high level brake light\t
• Unique canopy mounting system
